實時頻譜分析儀
產品名稱：實時頻譜分析儀 ? ? ? ? ? ? ? ? ? ? ? ? ? ??
產品型號：N9040B-RT1 Real-time Analysis up to 510 MHz
產品展商：北京凡實測控技術有限公司
產品品牌：美國是德
產品簡介：
Option RT1 adds the real-time spectrum analyzer (RTSA) capabilities to a new N9040B UXA signal analyzer. Adding RTSA to the UXA lets you see, capture and understand the most elusive signals—known or unknown.
Enables true gap-free real-time spectrum analysis in a high-perbance signal analyzer
- Quickly switch from swept spectrum analysis transient real-time analysis
Confidently capture the behavior of dynamic signals with durations as short as >15 μs (at 100% POI) with FMT
Seamlessly integrates with 89600 VSA software for thorough analysis of complex signals
- Measure over 75 modulation types, from custom OFDM or APSK to standard-based signals such as MIL-STD, GSM or LTE
- Use frequency-mask trigger to record culprit signals then playback through bs to Keysight vector signal generators, arbitrary waveb generators, or MATLAB
- Selectively trigger with TQT to find pulse outliers or trigger on specific communication bursts
Maximize your investment—add real-time spectrum analyzer capabilities to a UXA at a frb of the cost of a dedicated solution
主要特性與技術指標 ? ? ? ? ? ? ? ?
Functionality
Up to 510 MHz real-time bandb (requires Option B2X or B5X, which determines the maximum real-time BW) up to 26.5 GHz
Real-time displays include digital density (with digital persistence), swept density, spectrum, spectrogram, power vs. time and more
Frequency-mask trigger (FMT) and time qualified trigger (TQT) available as standard features
Perbance
>15 μs minimum signal duration for 100% probability of frequency mask triggering
Up to 75 dBc of spurious-free dynamic range across 510-MHz bandb
Frequency coverage up to 110 GHz with external mixing, 1.1 THz using 3rd party mixers
